Description

Features
  • 3 axes servo driving system: End sealing unit, the film transportation and feeding chain are driven by servo motors independently
  • User friendly machine with interface control system on a 8.4 inch colorful monitor
  • Independent control of bag length, cutting and feeding make the production changeover easy and quick
  • 50 sets of product data memory
  • Servo driving controlled for accurate bag length
  • The parameter of feeding position is set up and saved via the touch screen and it will be auto positioning whenever a production changeover occurs
  • Driving transmission parts are largely eliminated resulting in considerable reduction in noise, vibration, maintenance and enhance the accuracy and running capacity
Options
  • Auto-feeding system
  • Date coder
  • Stainless steel machine frame
  • Auto-splicer
  • CE or UL standards
Specifications
Model: HP-350-3V
  • Operating Speed: 20-250 pack/min
  • Bag Length 50mm - 750mm
  • Maximum Film Width: 350mm
  • Production Width: 20mm - 120mm
  • Production Height: 60mm
  • Machine Dimensions: Length 3860mm X Width 940mm X Height 1560mm
Model: HP-450-3V
  • Operating Speed: 20-250 pack/min
  • Bag Length 50mm - 750mm
  • Maximum Film Width: 450mm
  • Production Width: 20mm - 120mm
  • Production Height: 60mm
  • Machine Dimensions: Length 3860mm X Width 1000mm X Height 1560mm
Model: HP-350-3V
  • Operating Speed: 20-150 pack/min
  • Bag Length 50mm - 750mm
  • Maximum Film Width: 600mm
  • Production Width: 80mm - 230mm
  • Production Height: 60mm
  • Machine Dimensions: Length 3860mm X Width 1130mm X Height 1560mm
