Description

Features
  • Designed and manufactured using highest quality components.
  • Different strapping heights easy to set by pressing a button while the machine is in the desired position. Ten different programs available with ten different strapping heights for each.
  • Remote control available.
  • Warning light system.
  • Compression system in the arch compacts load and guides the strap to the correct position.
  • Approximate production 60 pallets per hour.
  • Mechanical tension adjustable through a holding strap system to get the highest tension.
  • Reisopack model 1900 head set in aluminium ensures long life of the machine.
  • Security system under the arch. If the machine contacts anything while moving down to the ready position, it immediately stops and returns to home
Specifications
  • Voltage: 220/ 380 V · 50 / 60 Hz. III-phase.
  • Electric Consumption: 2k VA.
  • Approx. Production: 60 to 80 pallets / hour.
  • Packaging Dimensions: 3 packages. 340 x 136 x 110 cm. / 120 x 67 x 187 cm. / 198 x 52 x 213 cm.
  • Strap Width: 8-12-15.5 mm. (Factory set).
  • Strap Thickness: 0.63-0.85 mm.
  • Heating System: Electrical heating. Heating temperature and cooling time adjustable.
  • Minimum Strapping Height: 130 mm.
Options
  • Available with automatic corner device.
