Description

Features
  • Own technology and manufacture using European components of highest quality.
  • Easy memorization of the different heights of strapping by pressing a button when the machine is in the desired position. Possibility of saving 10 different heights in 10 different programs.
  • Automatic corner applicator.
  • Pressing system in the arch to compact the loads and guide the strap.
  • Corner application air system by means of 4 telescopic L-shaped arms, adjustable to the size of the pallet.
  • Adjustable tension by means of high-tension clamp system.
  • Reisopack model 1900 aluminum strapping head ensures long life of the machine.
  • Approximate production of 50 pallets/hour with 4 corner boards and 3 straps.
  • Security system with inversion of the motor direction.
  • Failure warning lights
Specifications
  • Voltage: 220 V / 380 V · 50/60 Hz. III-phase.
  • Electric Consumption: 2 Kva.
  • Compressed Air Pressure: 6 bar.
  • Minimum Air Pressure: 4,5 bar.
  • Air Consumption: 200 nl (2901-2904) - 90 nl (2902).
  • Dimensions of the packed machine:
    • 901-2904 (3 packages): 382 x 202 x 166 cm. / 120 x 67 x 196 cm. / 165 x 165 x 117 cm.
    • 2903 (2 packages): 382 x 202 x 166 cm. / 120 x 67 x 196 cm.
  • Strapping Width: 8-12-15,5 mm. (must be set in Reisopack factory).
  • Strapping Thickness: 0,63-0,85 mm.
  • Welding System: By electric resistance. Adjustable welding temperature and cooling time.
  • Minimum Strapping Height: 130 mm.
  • Strapping cycle time with 3 straps and application of corners: 51 sec. (without corners: 38 sec.)​
Options
  • Model 2901-The strapping machine 2901 requires that in the entrance position, the shortest side of the pallet should be parallel to the machine.
  • Variant 2904 - The strapping machine 2904 requires that in the entry position, the longest side of the pallet should be parallel to the machine.
  • Variant 2903 - The strapping machine 2903 is prepared assemble the corner applicator and enables the entrance of the pallets from both sides.
